| water tank truck specification | |
| Truck brand | SINOTRUK |
| Driving type | Left hand drive |
| Over demesions(L*W*H) | 10350*2496*3633(mm) |
| Tank demesions (L*W*H) | 5050*2496*1620 (mm) |
| Tank capacity(L) | 20000 |
| Approaching angle/Departure angle(°) | 16/12(°) |
| F/R track base(mm) | 1205/3485 (mm) |
| Curb weight(kg) | 11360(Kg) |
| Max speed(km/h | 90 |
| Tank specification | |
| Tank volume | 20000L |
| Tank Material | carbon steel |
| Engine | |
| Model | WD615,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection |
| Fuel type | Diesel |
| Horse Power, max(kw/rpm) | 336HP |
| Emission | EURO II |
| Fuel tanker capacity (L) | 300 |
| Transmission | |
| Model | HW19710CL,10 forwards and 2 reverse |
| Brake system | |
| Service brake | Dual circuit compressed air brake |
| Parking brake | spring energy, compressed air operating on rear wheels |
| Auxiliary brake | Engine exhaust brake |
| Steering system | |
| Model | ZF8098 |
| Other specification | |
| Front axle | HF7 |
| Rear axle | ST16 |
| Color | Optional |
| Tire | 11.00-20 / 12.00-20/ 295/80R22.5 |
| Tire quantity | 11 |
| Electrical system | |
| Battery | 2X12V/165Ah |
| Alternator | 28V-1500kw |
| Starter | 7.5Kw/24V |
| Cab | |
| HOWO76 cab with one sleeper and air conditioner | |
